Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
Example
:HUWB:IF:GAIN:AUTO OFF
:HUWB:IF:GAIN:AUTO?
Couplings When either auto attenuation works (for example, with electrical attenuator), or the optimized
mechanical attenuator range is requested, the IF Gain setting is changed according to the following
rule:
Auto sets IF Gain to ON under any of the following conditions: the input attenuator is set to 0 dB
For other settings, Auto sets IF Gain to OFF
Preset
OFF
State Saved Yes
Range Auto | Man
IF Gain State
Selects the range of IF gain.
Remote Command
[:SENSe]:HUWB:IF:GAIN[:STATe] ON | OFF | 1 | 0
[:SENSe]:HUWB:IF:GAIN[:STATe]?
Example
:HUWB:IF:GAIN ON
:HUWB:IF:GAIN?
Notes Only applies to the RF input. Does not apply to baseband I/Q input
ON = high gain
OFF = low gain
Preset
OFF
State Saved Yes
Range Low Gain | High Gain
Transmit Mask Stitching State
Enables multiple IQ captures to cover required band width for Transmit Mask
measurement. This should only be enabled under these conditions:
–
Transmit Mask required band width > Maximum IFBW > = Demodulation
required bandwidth
–
Input signal is periodic
Remote
Command
[:SENSe]:HUWB:TRANsmit:MASK:STITching[:STATe] ON | OFF | 1 | 0
[:SENSe]:HUWB:TRANsmit:MASK:STITching [:STATe]?
Example
:HUWB:TRAN:MASK:STIT ON
:HUWB:TRAN:MASK:STIT?
Preset
OFF
State Saved Yes
Short Range Comms & IoT Mode User's &Programmer's Reference 527
