3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
>3.6 GHz by pressing the Up-arrow key, fails and results in an advisory message. If the equivalent
SCPI command is sent, this same message is generated as part of a “-221, Settings conflict” warning
Couplings When auto-coupled, the center frequency step size is set to 10% of the span
Preset Auto
ON
State Saved Saved in instrument state
Min/Max –/+ (The maximum frequency of the instrument)
That is, 27 GHz max freq instrument has a CF step range of +/- 27 GHz. Note that this is the maximum
frequency given the current settings of the instrument, so in External Mixing, for example, it is the
maximum frequency of the current mixer band
Status Bits/OPC
dependencies
non-overlapped
3.8.17 Marker
Enables you to select, set up and control the markers for the current measurement.
If there are no active markers, Marker selects Marker 1, sets it to Normal (POSition)
and places it at the center of the display. If the selected marker is OFF, it is set to
Normal and placed at the center of the screen, on the trace determined by the
Marker Trace rules.
3.8.17.1 Select Marker
Specifies the selected marker. The term “selected marker” is used throughout this
document to specify which marker will be affected when you change marker
settings, perform a Peak Search, etc.
This control appears above the menu panel, indicating that it applies to all controls
in the Marker menu panels. Select Marker is blanked if you select a tab whose
controls do not depend on the selected marker (for example, Counter).
In any menu that includes Select Marker, the first control is always Marker
Frequency|Time.
Notes The selected marker is remembered even when not in the Marker menu and is used if a search is done,
or a Band Function is turned on, or for Signal Track or Continuous Peak
Preset Marker 1
State Saved The number of the selected marker is saved in instrument state
Annunciation Appears in the marker results block label for Normal marker
1090 Short Range Comms & IoT Mode User's &Programmer's Reference
