3 Short-Range Comms & IoT Mode
3.10 Spurious Emissions Measurement
-50dBm, -50dBm
WLAN Mode:
-36dBm, -36dBm, -36dBm, -30dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -
50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm
State Saved Saved in instrument state
Min/Max -200.0 dBm/50.0 dBm
Abs Stop Limit
Determines the limit above which spurs will report a failing. If Abs Stop Limit Mode is
set to Auto, this is coupled to Abs Start Limit to make a flat limit line. If set to Man,
Abs Start Limit and Abs Stop Limit can take different values to make a sloped limit
line.
Abs Stop Limit Mode, when set to Couple, couples Abs Start Limit and Abs Stop
Limit to make a flat limit line. If set to Man, Abs Start and Abs Stop can take different
values to make a sloped limit line.
This parameter can send up to 20 values. The location in the list sent corresponds to
the range of the associated value. When sending the remote command, missing
values are not permitted; that is, if you want to change values 2 and 6, then you
must send all values up to 6. Subsequent values will remain as they were. The query
for this parameter always returns 20 values.
Remote
Command
:CALCulate:SPURious[:RANGe][:LIST]:
LIMit:ABSolute[:UPPer]:DATA:STOP
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>,
<ampl>
:CALCulate:SPURious[:RANGe][:LIST]:LIMit:ABSolute[:UPPer]:DATA:STOP?
Example
:CALC:SPUR:LIM:ABS:DATA:STOP -25, -25, -25, -25, -25, -25, -25, -25, -25, -
25, -25, -25, -25, -25, -25, -25, -25, -25, -25, -25
:CALC:SPUR:LIM:ABS:DATA:STOP?
Preset SA Mode: -5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -
5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -
5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -
5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -
5.00000000E+001, -5.00000000E+001, -5.00000000E+001, -5.00000000E+001
WCDMA Mode: -36dBm, -36dBm, -36dBm, -30dBm, -25dBm, -15dBm, -25dBm, -30dBm, -50dBm, -
50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm
LTETDD, LTEATDD, 5G NR Modes: -36dBm, -36dBm, -36dBm, -30dBm, -30dBm, -30dBm, -30dBm, -
50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm,
-50dBm, -50dBm
LTE, LTEAFDD, MSR Modes: -36dBm, -36dBm, -36dBm, -30dBm, -96dBm, -30dBm, -30dBm, -
50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm, -50dBm,
-50dBm, -50dBm
1462 Short Range Comms & IoT Mode User's &Programmer's Reference
