3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
Filter Type SCPI
Gaussian GAUSsian
Flattop FLATtop
Remote
Command
[:SENSe]:OBWidth:BANDwidth:SHAPe GAUSsian | FLATtop
[:SENSe]:OBWidth:BANDwidth:SHAPe?
Example
:OBW:BAND:SHAP GAUS
:OBW:BAND:SHAP?
Preset "Auto Couple" on page 1709 selects the preset value
State Saved Saved in instrument state
Annotation The annotation under RBW in the bottom left of the screen shows the type of filter or bandwidth that is
being used. The following examples illustrate this:
–3 dB (Normal) filter BW Res BW 300 Hz
–6 dB filter BW Res BW (–6 dB) 422 Hz
Noise filter BW Res BW (Noise) 317 Hz
Impulse filter BW Res BW (Impulse) 444 Hz
CISPR filter BW Res BW (CISPR) 200 Hz
MIL filter BW Res BW (MIL) 1 kHz
Flattop filter type Res BW (Flattop) 300 Hz
Backwards
Compatibility
SCPI
[:SENSe]:OBWidth:BWIDth:SHAPe
3.9.5 Display
Opens the Display menu, which lets you configure display items for the current
Mode, Measurement View or Window.
3.9.5.1 Meas Display
Contains controls for setting the display for the current Measurement, View or
Window.
x dB BW Boundaries On/Off
Turns the x dB BW Boundaries On or Off.
Remote Command
:DISPlay:OBWidth:WINDow[1]:XDB 0 | 1 | OFF | ON
:DISPlay:OBWidth:WINDow[1]:XDB?
Short Range Comms & IoT Mode User's &Programmer's Reference 1269
