7 Save/Recall/Print
7.3 Save
Cal Factor files are XML files, and contain the cal factor data and header data that
gives information on the power sensor.
The default path for Cal Factor Files is:
My Documents\<mode name>\data\PSCF
where <mode name> is the parameter used to select the mode with :INST:SEL (for
example, MRECEIVE for Measuring Receiver Mode). Hence, a Cal Factor file from any
measurement in the Measuring Receiver mode would be stored in:
My Documents\MRECEIVE\data\PSCF
Cal Factor files have the extension .xml. The default filename is <Sensor Model>_
<Sensor Serial Number>_0000.xml, where the 4-digit number is the lowest
number that does not conflict with any filename in the current directory. If the
sensor model or serial number is blank, the default filename is PSCF_0000.xml.
Remote Command
:MMEMory:STORe:PSCFactor <file_name>
Example
:MMEM:STOR:PSCF "myPSCF.xml"
Notes If the save is initiated via SCPI, and the file already exists, the file will be overwritten
Using the C: drive is strongly discouraged, since it runs the risk of being overwritten during an
instrument software upgrade
Both single and double quotes are supported for any filename parameter over SCPI
Dependencies Only appears if you have the proper option installed in your instrument
7.3.54 Recording
Lets you save to a file data being acquired by the measurement, so that it can later
be recalled and played back as though it were coming from the input.
You may specify a data type (for example, I/Q data) and choose a file to which to
save the data.
The recording and playback of signal data files is a multi-step process that involves
controls in several menus.
The menus that are involved in Record/Playback are:
–
Save, Recording (this menu)
–
Recall, "Recording" on page 2244 (under the Recall hardkey or the Recall icon in
the File panel)
–
Sweep, Recording tab
–
Sweep, Playback tab
–
Input/Output, "Data Source" on page 2101 tab
Short Range Comms & IoT Mode User's &Programmer's Reference 2303
