3 Short-Range Comms & IoT Mode
3.10 Spurious Emissions Measurement
Adjust Range for Min Clipping
Sets the combination of attenuation and gain based on the current measured signal
level so that clipping will be at a minimum.
This is an "immediate action" function, that is, it executes once, when the key is
pressed.
This key does not appear in measurements that do not support this functionality.
Remote Command
[:SENSe]:POWer[:RF]:RANGe:OPTimize IMMediate
Notes Executing Adjust Range for Min Clipping initiates the measurement
Dependencies Does not appear in the Swept SA and Monitor Spectrum measurements
Pre-Adjust for Min Clipping
If this function is ON, it applies the adjustment described under Adjust Range For Min
Clipping each time a measurement restarts. Therefore, in Continuous measurement
mode, it only executes before the first measurement.
Remote Command
[:SENSe]:POWer[:RF]:RANGe:OPTimize:ATTenuation OFF | ON | ELECtrical |
COMBined
[:SENSe]:POWer[:RF]:RANGe:OPTimize:ATTenuation?
Notes Because there is no attenuator control available in these models, the control displays only ON and
OFF choices. However, for SCPI compatibility with other platforms, all three parameters
(ELECtrical, COMBined, and ON) are honored and all are mapped to ELECtrical, so if any of
these three parameters is sent, a subsequent query will return ELEC
Dependencies Does not appear in the Swept SA and Monitor Spectrum measurements
Preset OFF for Swept SA measurement; ON for all other measurements that support Pre-Adjust for Min
Clipping
State Saved Saved in instrument state
Adjustment Algorithm
The algorithm for the adjustment is documented below:
Short Range Comms & IoT Mode User's &Programmer's Reference 1381
