Keysight x-series Instruction Manual

8 Trigger
8.1 Trigger
Couplings The same offset is used in the Gate Source selection of the period timer
Preset 0 s
State Saved Saved in instrument state
Min -10.000 s
Max 10.000 s
8.1.10 Reset Offset Display
Resets the value of the periodic trigger offset display setting to 0.0 seconds. The
current displayed trigger location may include an offset value defined with the Offset
key. Pressing this control redefines the currently displayed trigger location as the
new trigger point that is 0.0 s offset. The Offset control can then be used to add
offset relative to this new timing.
Remote Command
:TRIGger[:SEQuence]:FRAMe:OFFSet:DISPlay:RESet
Example
:TRIG:FRAM:OFFS:DISP:RES
Dependencies Only appears when Periodic Timer is selected as the Trigger or Gate Source
8.1.11 Offset Adjust (Remote Command Only)
Lets you advance the phase of the frame trigger by the amount you specify. It does
not work in the same way as the related front panel keys.
The command does not change the period of the trigger waveform. If the command
is sent multiple times, it advances the phase of the frame trigger an additional
amount each time it is sent. Negative numbers are permitted.
Remote Command
:TRIGger[:SEQuence]:FRAMe:ADJust <time>
Example
:TRIG:FRAM:ADJ 1.2 ms
Notes Note also that Offset is used only when the sync source is set to OFF, otherwise delay is used, see
section "Trigger Delay" on page 2343
An increase in the "offset" parameter, either from the knob or the SCPI adjust command, serves to
delay the timing of the trigger event
The front panel interface (for example, the knob) and the :TRIG:FRAM:OFFS command adjust the
accumulated offset, which is shown on the active function display. However, the actual amount sent to
the hardware is the delta value, that is, the current offset value minus the previous offset value
When the SCPI command is sent the value shown on the control (and the Active Function, if this
happens to be the active function) is updated by increasing it (or decreasing it if the value sent is
negative) by the amount specified in the SCPI command
This is no query for this command
Dependencies The invalid data indicator turns on when the offset is changed, until the next sweep/measurement
2353 Short Range Comms & IoT Mode User's &Programmer's Reference
