3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
–
The RBW to be used in the calculations is the equivalent –3 dB bandwidth of the
current RBW filter
–
The rules apply whether in swept spans, zero span, or FFT spans
Ranges
Option Option # Phase Noise Option Range
No EPx Option 1 Best Close-in [offset < 20 kHz]
2 Best Wide-offset [offset > 30 kHz]
3 Fast Tuning [same as Best Close-In]
EP0 4 Best Close-in [offset < 600 kHz]
1 Balanced [offset < 600 kHz]
5 Best Spurs [offset < 600 kHz]
2 Best Wide-offset [offset > 800 kHz]
3 Fast Tuning [same as Best Close-In]
EP1 1 Best Close-in [offset < 140 kHz]
2 Best Wide-offset [offset > 160 kHz]
3 Fast Tuning [single loop]
EP2, EP3, EP5 1 Best Close-in [offset < 70 kHz]
2 Best Wide-offset [offset > 100 kHz]
3 Fast Tuning [medium loop bw]
EP4 1 Best Close-in [offset < 90 kHz]
2 Best Wide-offset [offset > 130 kHz]
3 Fast Tuning [same as Best Close-In]
IF Gain
Enables you to set IF Gain to Auto (see "IF Gain Auto " on page 526), Low Gain (OFF)
or High Gain (ON: extra 10 dB). These settings affect sensitivity and IF overloads.
To take full advantage of the RF dynamic range of the instrument, a switched IF
amplifier with approximately 10 dB of gain is available. When it can be turned on
without an overload, the dynamic range is always better with it on than off.
Only applies to the RF input. Does not apply to baseband I/Q input.
IF Gain Auto
Activates the auto rules for IF Gain
Remote
Command
[:SENSe]:HUWB:IF:GAIN:AUTO[:STATe] ON | OFF | 1 | 0
[:SENSe]:HUWB:IF:GAIN:AUTO[:STATe]?
526 Short Range Comms & IoT Mode User's &Programmer's Reference
