7 Save/Recall/Print
7.2 Recall
The CSV format contains the following data:
File Type
Application Name: Measurement Name
Version and Model Number
Loss Comp Data
Below is an example of a valid CSV Loss Compensation file:
[Filetype LossCompensation]
[NF:NFIG]
Ver. ***, Model ***
10, 1.0000
20, 2.0000
30, 3.0000
40, 4.0000
50, 5.0000
60, 6.0000
7.2.45 Data Pattern
Lets you choose a file from which to import the data pattern for generating an NRZ
waveform to be used by the Audio Generator ARB.
Data Pattern files are CSV files, containing the bit pattern data in a form that can be
imported into Excel or similar spreadsheets.
Data Pattern files have the extension .csv.
Remote Command
:MMEMory:LOAD:RTS:DATA:PATTern <filename>
Example Import the data pattern from the file myDataPattern.csv in the current path:
:MMEM:LOAD:RTS:DATA:PATT "myDataPattern.csv"
Dependencies Errors are reported if the file is empty or missing, or if the file type does not match, or if there is a
mismatch between the file type and the destination data type
Annotation After recall is complete, an advisory is displayed in the message bar confirming the sync pattern
strings were loaded
Status Bits/OPC
dependencies
Sequential - aborts the current measurement
7.2.46 Signal Configuration
Selects a Signal Studio N7610C scp file from which to import the demod settings to
the HRP UWB measurement.
Short Range Comms & IoT Mode User's &Programmer's Reference 2253
