6 Input/Output
6.1 RF Source
6.1.6.3 Power Ref
Lets you toggle the state of the power reference. When you use a power reference,
the signal generator outputs an RF power that is set relative to the reference power
by the value entered under Source>Amplitude>RF Power as follows:
Output power = reference power + entered power
Where:
–
reference power equals the original RF Power entered under
Source>Amplitude>RF Power and set as the reference power
–
entered power equals a new value entered under Source>Amplitude>Amptd
Offset
For more information on Reference Frequency, see "Set Reference Power" on page
1928.
Remote Command
:SOURce:POWer:REFerence <ampl>
:SOURce:POWer:REFerence?
Example
:SOUR:POW:REF 0.00 dBm
Dependencies Unavailable and grayed-out when "List Sequencer" on page 1931 is ON
Couplings Coupled to "Set Reference Power" on page 1928, such that pressing Set Reference Power updates
the reference power with the current output power
Preset 0.00 dBm
Min -125.00 dBm
Max 10.00 dBm
Auto Function
Remote Command
:SOURce:POWer:REFerence:STATe OFF | ON | 0 | 1
:SOURce:POWer:REFerence:STATe?
Example
:SOUR:POW:REF:STATe ON
Preset
OFF
6.1.6.4 Power Unit
Modifies the units for RF Power and Power Ref. The change is immediate and does
not force a restart.
Remote
Command
:SOURce:POWer[:LEVel][:IMMediate][:AMPLitude]:UNIT DBM | W | V | DBUV
:SOURce:POWer[:LEVel][:IMMediate][:AMPLitude]:UNIT?
Example Set the RF Power units to volts:
1929 Short Range Comms & IoT Mode User's &Programmer's Reference
