Keysight x-series Instruction Manual

6 Input/Output
6.8 Trigger Output
NOTE
In some software released in 2018 and 2019, the SCPI command for this
function was as below:
:TRIGger:SOURce:INTernal[:SEQuence]:OUTPut
S1Marker|S2Marker|S3Marker|S4Marker|OFF
It was necessary to change this SCPI in release A.24.00 due to internal conflicts
in the software. User code written for the A.22.xx or A.23.xx instrument software
which used the old form must be rewritten to use the form below.
Remote Command
:TRIGger[:SEQuence]:INTernal:SOURce:OUTPut S1Marker | S2Marker | S3Marker |
S4Marker | PARB | OFF
:TRIGger[:SEQuence]:INTernal:SOURce:OUTPut?
Example
:TRIG:INT:SOUR:OUTP S1M
Notes PARB (Per ARB) -A synchronization trigger that is generated by the ARB at the beginning of each
repetition of playing the signal
Dependencies Only available on VXT models M9420A, M9410A/11A/15A/16A and M9410E/11E/15E/16E
Preset Unaffected by Preset but preset by Restore Input/Output Defaults or Restore System Defaults->All.
The value is Mode-dependent:
Power Amplifier Mode: S1Marker
All other Modes: OFF
State Saved Saved in instrument state
6.8.11 Source Internal Trig Out Polarity
Sets the output to the Source Internal trigger line to trigger on either the positive or
negative polarity.
NOTE
In some software released in 2018 and 2019, the SCPI command for this
function was as below:
:TRIGger:SOURce:INTernal[:SEQuence]:OUTPut:POLarity
POSitive|NEGative
It was necessary to change this SCPI in release A.24.00 due to internal conflicts
in the software. User code written for the A.22.xx or A.23.xx instrument software
which used the old form must be rewritten to use the form below.
Remote Command
:TRIGger[:SEQuence]:INTernal:SOURce:OUTPut:POLarity POSitive | NEGative
:TRIGger[:SEQuence]:INTernal:SOURce:OUTPut:POLarity?
Example
:TRIG:INT:SOUR:OUTP:POL POS
Dependencies Only available on VXT models and M9410E/11E/15E/16E
Preset Unaffected by Preset, but set to POSitive by Restore Input/Output Defaults or Restore System
Short Range Comms & IoT Mode User's &Programmer's Reference 2176

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
