Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is 0
0, 0, 0, 0, 0, 0 | 0, 0, 0, 0, 0, 0
State Saved Saved in instrument state
Min/Max -150.0 dB/50.0 dB
Fail Mask
Accesses a menu that enables you to select one of the logics for the fail conditions
between the measurement results and the test limits. The setting defines the type of
testing to be done at any custom offset frequencies. The measured powers are
tested against the absolute values defined with [:SENSe]:ACP:OFFSet
[n]:INNer:LIST:ABSolute, or the relative values defined with
[:SENSe]:ACP:OFFSet[n]:INNer:LIST:RPSDensity and
[:SENSe]:ACP:OFFSet[n]:INNer:LIST:RCARrier.
You can turn off (not use) specific offsets with [:SENSe]:ACP:OFFSet
[n]:INNer:LIST:STATe.
Option SCPI Description
Absolute
ABSolute
Fail is shown if one of the absolute ACP measurement results is
larger than the limit for Abs Limit
Relative
RELative
Fail is shown if one of the relative ACP measurement results is
larger than the limit for Rel Lim (Car) or Rel Lim (PSD)
Abs AND Rel
AND
Fail is shown if one of the absolute ACP measurement results is
larger than the limit for Abs Limit and one of the relative ACP
measurement results is larger than the limit for Rel Lim (Car) or
Rel Lim (PSD)
Abs OR Rel
OR
Fail is shown if one of the absolute ACP measurement results is
larger than the limit for Abs Limit or one of the relative ACP
measurement results is larger than the limit for Rel Lim (Car) or
Rel Lim (PSD)
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:TEST ABSolute | AND | OR | RELative,…
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:TEST?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS2:INN:LIST:TEST ABS,ABS,ABS,ABS,ABS,ABS
:ACP:OFFS2:INN:LIST:TEST?
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is AND
AND, AND, AND, AND, AND, AND | AND, AND, AND, AND, AND, AND
State Saved Saved in instrument state
Range
ABSolute|AND|OR|RELative
Short Range Comms & IoT Mode User's &Programmer's Reference 943
