6 Input/Output

6.1 RF Source

Select PXI Line

Controls which PXI_TRIG[0..7] backplane line is used for the trigger source.

Only appears in modular analyzer products.

Remote Command

:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:LINE <line>

:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:LINE?

Example

:SOUR:RAD:ARB:TRIG:PXI:LINE 2

Dependencies Unavailable and grayed-out when "Trigger Source" on page 1988 is not set to PXI

Not available in E7760B

Preset 0

State Saved Saved in instrument state

Range [0,7]

PXI Trigger Delay

Lets you toggle the state and value of PXI trigger delay. The value you enter sets a

delay time between when an PXI trigger is received and when it is applied to the

waveform.

Only active if "Trigger Source" on page 1988 is PXI.

Remote Command

:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:DELay <time>

:SOURce:RADio:ARB:TRIGger[:SOURce]:PXI:DELay?

Example

:SOUR:RAD:ARB:TRIG:PXI:DEL 100ns

:SOUR:RAD:ARB:TRIG:PXI:DEL?

Notes PXI trigger delay time set by users will be rounded to the nearest integer multiple of the resolution

Dependencies Unavailable and grayed-out when "Trigger Source" on page 1988 is not PXI

Not available in E7760B

Preset 1 ms

Min VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E: -10 s

Max

Instrument/Condition Value Derivation

VXT models M9410A/11A/15A/16A 11.45324612 s 2.666667ns * (2^32-1)

M9410E/11E/15E/16E 11.45324612 s 2.666667ns * (2^32-1)

Continuous – Trigger + Run” trigger 11.45324612 s 2.666667ns * (2^32-1)

Other trigger conditions 17.17986918 s 4 ns *(2^32-1)

All Others 8.589934588 s 4ns * (2^31 – 1)

1993 Short Range Comms & IoT Mode User's &Programmer's Reference
