Keysight x-series Instruction Manual

6 Input/Output
6.5 Corrections
Min/Max
Min Max
Freq 0 Hz 1 THz
Amptd -1000 dBm +1000 dBm
6.5.15 Set (Replace) Data (Remote Command Only)
Accepts an ASCII series of alternating frequency and amplitude points, each value
separated by commas.
The values sent in the command totally replace all existing correction points in the
specified set.
An Ampcor array can contain 2000 points maximum.
Remote
Command
[:SENSe]:CORRection:CSET[1]|2|…|16:DATA <freq>, <ampl>, ...
[:SENSe]:CORRection:CSET[1]|2|…|16:DATA?
Example
:CORR:CSET1:DATA 10000000,-1.0,20000000,1.0
This defines two correction points at (10MHz, -1.0dB) and (20MHz, 1.0dB) for correction set 1
Preset Empty after Restore Input/Output Defaults. Survives a shutdown or restart of instrument application
(including a power cycle)
State Saved Saved in instrument state
Min Freq: 0 Hz
Amptd: -1000 dBm
Max Freq: 1 THz
Amptd: +1000 dBm
6.5.16 Correction Group Range Data (Remote Command Only)
Accepts an ASCII series of alternating start frequency, stop frequency and file
names, each value separated by commas.
The values sent in the command replace the content of correction group.
The default path for CSV files is:
D:\My Documents\amplitudeCorrections\
Remote
Command
[:SENSe]:CORRection:CSET:GROup[1]|2|…|10:DATA <startFre-
q>,<stopFreq>,<filename1>,<filename2>,…,<filename8>
See Notes below for explanation of the <filenameN> parameters
[:SENSe]:CORRection:CSET:GROup[1]|2|…|10:DATA?
2141 Short Range Comms & IoT Mode User's &Programmer's Reference
