3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Min/Max -200 dBm/200 dBm
Backwards
Compatibility SCPI
[:SENSe]:MCPower:CARRier[1]|2[:POWer]
Total Power Ref (Modes: LTEAFDD, LTEATDD, 5G NR, MSR)
Sets the multi-carrier power reference. This is used when Power Ref is Manual and
"Measurement Type" on page 947 is Total Power.
When set to Auto, the carrier power result reflects the measured power value in the
selected reference carrier.
When set to Man, the result is referenced to the last measured value, or you may
specify the reference for the multi-carrier power measurement. Relative values are
displayed, referenced to the “Power Reference” value.
Remote Command
[:SENSe]:ACPower:CARRier[1]|2[:POWer] <real>
[:SENSe]:ACPower:CARRier[1]|2[:POWer]?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:CARR 10
:ACP:CARR?
Notes Although the default value is defined, the value is recalculated by the measurement result just after
measurement
Note that Carrier subopcode 2 is not supported in some Modes. In those cases, Carrier subopcode 1
is used for both BTS and MS and commands with subopcode 2 are accepted without error but ignored
The Unit Terminators differ depending on whether or not the mode supports Y Axis Unit and also
which Y Axis Unit is selected
Dependencies Enabled when "Measurement Type" on page 947 is Total Power and "Power Ref" on page 948 is
Manual
Preset 0.0
State Saved Saved in instrument state
Min/Max -200 dBm/200 dBm
Backwards
Compatibility SCPI
[:SENSe]:MCPower:CARRier[1]|2[:POWer]
PSD Ref
Sets manual PSD reference.
This control has two different forms, depending on the currently-selected Mode:
Short Range Comms & IoT Mode User's &Programmer's Reference 953
