3 Short-Range Comms & IoT Mode

3.2 Modulation Analysis Measurement

If the Modulation Format is BPSK and 2FSK, the available values are 1, 2, 4, 5, 10 and 20

Numeric entries are rounded to the nearest valid value

Preset 10

State Saved Yes

Min/Max 1/20

Ref Filter

This control enables you to select the Ref Filter that represents the cascaded

transmit and receive filter.

Remote

Command

[:SENSe]:EVM:FILTer:REFerence RCOSine | RRCosine | GAUSsian | RECTangle |

HSINe

[:SENSe]:EVM:FILTer:REFerence?

Example

:EVM:FILT:REF GAU

:EVM:FILT:REF?

Notes When the Half Sine filter is selected, the Alpha control will be set to 0.9 and grayed out

Preset HSIN

State Saved Yes

Range Raised Cosine | Root Raised Cosine | Gaussian | Rectangular | Half Sine

Alpha

This control enables you to determine the filter characteristics of the Raised cosine

and Root-raised cosine filters used by the analyzer's digital demodulator. These

characteristics apply to both of the Ref filters.

Remote Command

[:SENSe]:EVM:FILTer:ALPHa <real>

[:SENSe]:EVM:FILTer:ALPHa?

Example

:EVM:FILT:ALPH 0.5

:EVM:FILT:ALPH?

Dependencies This control is available for Raised Cosine and Root Raised Cosine filters only

Preset 0.9

State Saved Yes

Min/Max 0.05/1

Short Range Comms & IoT Mode User's &Programmer's Reference 279
