3 Short-Range Comms & IoT Mode

3.3 LoRa (CSS) Demodulation Measurement

Remote Command

:CALCulate:LORA:MARKer[1]|2|...|12:MINimum

Example

:CALC:LORA:MARK:MIN

State Saved Not part of saved state

Pk-Pk Search

Looks for the peak and the pit on the trace where the specified marker locates and

displays the amplitude and frequency (or time, if in the time domain) differences

between the peak and the pit. The specified marker and its reference marker are

placed on the pit and peak of the trace, respectively.

The rules of finding the peak follows the rule of the peak search. The pit is found

simply by identifying the point having the lowest Y-axis value on the trace.

Remote Command

:CALCulate:LORA:MARKer[1]|2|...|12:PTPeak

Example

:CALC:LORA:MARK:PTP

Dependencies Pk-Pk Search is not available when Coupled Markers is on

Couplings The selected marker becomes a delta marker if not in the delta mode

State Saved Not part of saved state

Marker Delta

Sets the specified marker to be a delta marker and moves its reference marker to

the same position where the selected locates.

Mkr -> CF

Sets the center frequency to the X-axis value of the specified marker if the abscissa

is frequency. The marker stays at its original frequency, so that it moves to the

center of the display. In delta marker mode, this function sets the center frequency

to the x-axis value of the delta marker.

If the currently selected marker was not on, it will be switched on and positioned at

the center of the window as a normal marker.

Remote Command

:CALCulate:LORA:MARKer[1]|2|...|12[:SET]:CENTer

Example

:CALC:LORA:MARK4:CENT

Dependencies This function is not available (control is grayed out) when the abscissa is time

Short Range Comms & IoT Mode User's &Programmer's Reference 393
