Keysight x-series Instruction Manual

6 Input/Output
6.1 RF Source
Center Frequency Maximum IF BW
330 MHz ~ 380 MHz (without Option LFE) (CF – 330 MHz) * 2
380 MHz ~ 550 MHz 100 MHz
550 MHz ~ 1310 MHz 200 MHz
1310 MHz ~ 2000 MHz 600 MHz
2000 MHz ~ 25.9 GHz 1200 MHz
25.9 GHz ~ 26.5 GHz Min(Max BW by option, 2*(26.5 GHz-Center Freq))
Run-Time Scaling
Lets you adjust the run-time scaling value. The run-time scaling value is applied in
real-time while the waveform is playing.
Remote Command
:SOURce:RADio:ARB:RSCaling <real>
:SOURce:RADio:ARB:RSCaling?
Example
:SOUR:RAD:ARB:RSC 100.00
Notes Cannot be set in EXM and VXT. Grayed-out in menu, and the value is fixed at 70.00%
Dependencies When a new waveform is selected for playback the settings contained within the associated waveform
header file are applied to the ARB. The run-time scaling is one of the values stored within the header
file. If the newly selected waveform file has an associated header file, the run-time scaling is updated
with the value from the header file. The run-time scaling will remain unchanged if the newly selected
waveform does not have an associated header file
Preset 70.00 %
Min 1.00 %
Max 100.00 %
Baseband Freq Offs
Lets you adjust the value by which the baseband frequency is offset relative to the
carrier.
Remote Command
:SOURce:RADio:ARB:BASeband:FREQuency:OFFSet <freq>
:SOURce:RADio:ARB:BASeband:FREQuency:OFFSet?
Example
:SOUR:RAD:ARB:BAS:FREQ:OFFS 0.00 Hz
Dependencies When a new waveform is selected for playback the settings contained within the associated waveform
header file are applied to the ARB. The baseband frequency offset is one of the values stored within
the header file. If the newly selected waveform file has an associated header file, the baseband
frequency offset is updated with the value from the header file. The baseband frequency offset will
remain unchanged if the newly selected waveform does not have an associated header file
Not available in E7760B
1983 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
