3 Short-Range Comms & IoT Mode
3.5 Channel Power Measurement
Min The minimum frequency in the currently selected mixer band + 5 Hz
If the knob or step keys are being used, also depends on Span
Max The maximum frequency in the currently selected mixer band – 5 Hz
If the knob or step keys are being used, also depends on Span
I/Q Center Freq
Sets the Center Frequency to use when the I/Q input is selected, even if the I/Q
input is not the input which is selected at the time the command is sent. Note that
Center Frequency in the Frequency menu on the front panel always applies to the
currently selected input.
Remote
Command
[:SENSe]:FREQuency:IQ:CENTer <freq>
[:SENSe]:FREQuency:IQ:CENTer?
Example
:FREQ:IQ:CENT 30 MHz
Notes This command is the same in all Modes, but the parameter is Measurement Global, so the value is
independent in each Mode and common across all measurements in the Mode
Preset 0 Hz
State Saved Saved in instrument state
Min/Max –/+40.049995 MHz
Span
Changes the displayed frequency range symmetrically about the center frequency.
While adjusting Span, Center Frequency is held constant, which means that both
Start Frequency and Stop Frequency will change.
If Span is set to a value greater than the maximum allowable span of the instrument,
an error message is generated indicating the data is out of range and was clipped to
upper limit.
The default (and minimum) Span is calculated using the number of carriers and the
carrier width where;
Span = (Upper Carrier Freq + (max offset IBW * (1 + alpha)) / 2) - (Lower Carrier Freq
- (max offset IBW * (1 + alpha)) / 2)
If the RRC Filter is on, then span is increased by a factor of 1 + Filter Alpha.
See "Span Presets" on page 616
Remote Command
[:SENSe]:CHPower:FREQuency:SPAN <freq>
[:SENSe]:CHPower:FREQuency:SPAN?
Example
:CHP:FREQ:SPAN 10 MHz
614 Short Range Comms & IoT Mode User's &Programmer's Reference
