3 Short-Range Comms & IoT Mode
3.10 Spurious Emissions Measurement
Span
Same as the Span column under the Bandwidth index tab. See "Span" on page
1440.
Attenuation
Defines attenuation value for each range:
ON
The Attenuation value under AMPTD Y Scale is used
OFF
This value is used as mechanical attenuation value without electric attenuation
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:ATTenuation <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_
ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>, <rel_ampl>
[:SENSe]:SPURious[:RANGe][:LIST]:ATTenuation?
Example
:SPUR:ATT 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB,
10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB
:SPUR:ATT?
Couplings “---“ is displayed as value when Auto state is ON, to indicate attenuation value under AMPTD Y Scale is
being used
Preset 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB, 10dB,
10dB, 10dB, 10dB, 10dB, 10dB
State Saved Saved in instrument state
Min/Max 0 dB/70 dB
Auto Function
Remote
Command
[:SENSe]:SPURious[:RANGe][:LIST]:ATTenuation:AUTO OFF | ON | 0 | 1, OFF | ON
| 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 |
1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1,
OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF |
ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON | 0 | 1, OFF | ON |
0 | 1, OFF | ON | 0 | 1
[:SENSe]:SPURious[:RANGe][:LIST]:ATTenuation:AUTO?
Example
:SPUR:ATT:AUTO 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
:SPUR:ATT:AUTO?
Preset
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON,
ON
State Saved Saved in instrument state
Range Auto | Man
Short Range Comms & IoT Mode User's &Programmer's Reference 1451
