3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
:SEM:OFFS:LIST:STOP:SABS:COUP ON, ON, ON, ON, ON, ON
:SEM:OFFS:LIST:STOP:SABS:COUP?
Notes Comma separated list of values
OFFSet 1 is for BTS, 2 for MS. Default is BTS
Couplings Coupled to Abs2 Start if Auto is selected, that is, the Stop value is equal to the Start value
Preset For WLAN Mode:
0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0
dBm
For other Modes:
0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm | 0 dBm, 0
dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm, 0 dBm
For WLAN Mode:
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON
For other Modes:
ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON, ON | ON, ON, ON, ON, ON, ON, ON,
ON, ON, ON, ON, ON
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min -200 dBm
Max 50 dBm
Fail Mask2
Selects the logic operation for fail conditions between the measurement results and
the test limits:
(Primary Fail Mask
selection) OR Abs2
OR
Checks against both Primary and Abs2 limits. The test fails
if either of the limits is broken
(Primary Fail Mask
selection) AND Abs2
AND
Checks against both Primary and Abs2 limits. The test fails
if both of the limits are broken
Abs2 Disabled
OFF
Fail Mask2 is disabled
Note that the Primary Fail Mask selection is set by "Fail Mask" on page 1133.
Examples:
–
when Fail Mask is Abs AND Rel and Fail Mask2 is OR Abs2, “(Abs AND Rel) OR
Abs2” is displayed in the column
–
when Fail Mask is Absolute and Fail Mask2 is And Abs2, “(Absolute) AND Abs2”
is displayed in the column
You can turn off (not use) specific offset channels remotely using:
Short Range Comms & IoT Mode User's &Programmer's Reference 1137
