Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.10 Spurious Emissions Measurement
5; for Trace 6, it presets to Trace 4
Operand 2: Trace number minus 1 (wraps at 1). For example, for Trace 1, Operand 2 presets to Trace
6; for Trace 6, it presets to Trace 5
State Saved Operands 1 and 2 for each trace are stored in instrument state
Offset
Used by the Log Offset math function.
Example The following example is for the Swept SA measurement
Set Trace 3 to Log Offset trace math function, set the First Trace operand (for Trace 3) to Trace 1, leave
the Second Trace operand (for Trace 3) unchanged (it is irrelevant for this function) and set the Log
Offset (for Trace 3) to -6 dB:
:CALC:MATH TRACE3,LOFF,TRACE1,TRACE2,-6.00,0
State Saved The Log Offset value for each trace is saved in Instrument State
Min –100 dB
Max 100 dB
Reference
Used by the Log Diff math function.
Example The following example is for the Swept SA measurement
Set Trace 3 to Log Diff trace math function, set the First Trace operand (for Trace 3) to Trace 1, set the
Second Trace operand (for Trace 3) to Trace 2, and set the Log Difference reference (for Trace 3) to -6
dBm:
:CALC:MATH TRACE3,LDIF,TRACE1,TRACE2,0,-6.00
State Saved The Log Difference reference value for each trace is saved in instrument state
Min/Max Same as reference level
3.10.10.4 Trace Function
Contains controls to:
–
Copy and Exchange traces
–
Preset or Clear all traces
Short Range Comms & IoT Mode User's &Programmer's Reference 1505
