3 Short-Range Comms & IoT Mode
3.4 HRP UWB Demodulation Measurement
State Saved Saved in instrument state
Range
1|…|32
Delta Length
Sets the zero interpolation of the code to create a sync symbol (Si) for UWB
synchronization header (SHR). Available Delta Length choices also depend on which
"Channel" on page 487 is selected, as described in Table 15-4 of the IEEE 802.15.4
standard.
Remote
Command
[:SENSe]:HUWB:SHR:DELTa:LENGth L4 | L16 | L64
[:SENSe]:HUWB:SHR:DELTa:LENGth?
Example
:HUWB:SHR:DELT:LENG L64
Couplings Only value 4 (L4) can be used when SHR Code Index is from 9 to 32
Only value 16 (L16) can be used for wideband channel (channel number 4, 7, 11, 15) when SHR Code
Index is from 1 to 8
Values 16 (L16) and 64 (L64) can be used for other channels when SHR Code Index is from 1 to 8
Preset
L16
State Saved Saved in instrument state
Range
4|16|64
SYNC Length
Sets the number of sync symbol (Si) used to comprise the SYNC portion for UWB
synchronization header (SHR).
Remote
Command
[:SENSe]:HUWB:SHR:SYNC:LENGth L16 | L24 | L32 | L48 | L64 | L96 | L128 | L256
| L512 | L1024 | L4096
[:SENSe]:HUWB:SHR:SYNC:LENGth?
Example
:HUWB:SHR:SYNC:LENG L128
Couplings Valid values depend on "PHY Mode" on page 501:
PHY Mode Valid Values
Non-ERDEV 16, 64, 1024 and 4096 symbols (L16, L64, L1024, L4096)
Note that 4096 is not allowed if "Delta Length" on page 504 is 64
ERDEV-BPRF PHY 16, 64, 1024 and 4096 symbols (L16, L64, L1024, L4096)
ERDEV-HPRF PHY 16, 24, 32, 48, 64, 96, 128, and 256 symbols (L16 -L256)
Preset
L64
State Saved Saved in instrument state
Range 16 symbols | 24 symbols | 32 symbols | 48 symbols | 64 symbols | 96 symbols | 128 symbols | 256
symbols | 1024 symbols | 4096 symbols
504 Short Range Comms & IoT Mode User's &Programmer's Reference
