2 User Interface
2.19 Fullscreen
2.19 Fullscreen
The Fullscreen button is in the "Control Bar" on page 135, at the lower right corner
of the display.
When Full Screen is pressed the measurement window expands horizontally over
the entire instrument display. The screen graticule area expands to fill the available
display area.
It turns off the display of the menu panel, however the controls that drop down from
the Meas Bar and on-screen annotation are still available, and you can still drag the
trace and markers and perform a pinch zoom, so you can still operate the
instrument.
Pressing Full Screen again while Full Screen is in effect cancels Full Screen.
You can get even more screen area for your data display by turning off the Meas Bar
using the Annotation tab of the Display menu)
Full Screen is canceled by the Preset key.
Remote
Command
:DISPlay:FSCReen[:STATe] OFF | ON | 0 | 1
:DISPlay:FSCReen[:STATe]?
Notes This was set to Off by :SYST:DEF MISC in MXA1, but not by Preset. It is no longer set Off by :SYST:DEF
MISC, since it is now meas global instead of mode global
Preset Unaffected by Preset but set to Off by Restore Misc Defaults or shutdown and restart
State Saved Not saved in instrument state
Backwards
Compatibility
SCPI
:DISPlay:MENU[:STATe] OFF | ON | 0 | 1
This emulates ESA full screen functionality, which is the same as the FSCReen command in PSA except
that the sense of on/off is reversed (that is, OFF means the menus are OFF, so Fullscreen is ON) and the
default is ON (meaning Fullscreen is OFF)
Backwards
Compatibility
Notes
In ESA/PSA, Full Screen was turned on with a softkey, so pressing any other key turned Full Screen off.
In the X-Series, because a hardkey is provided to turn this function on and off, pressing any other key
no longer turns off Full Screen
