3 Short-Range Comms & IoT Mode
3.6 Power Stat CCDF Measurement
Remote
Command
:DISPlay:PSTatistic:VIEW[1]:WINDow2:TRACe:X[:SCALe]:PDIVision <rel_ampl>
:DISPlay:PSTatistic:VIEW[1]:WINDow2:TRACe:X[:SCALe]:PDIVision?
Example
:DISP:PST:VIEW:WIND2:TRAC:X:PDIV 10
:DISP:PST:VIEW:WIND2:TRAC:X:PDIV?
Notes The CCDF measurement has the trace display only in Window 2, because values other than “2” are not
available as the sub-op code
Preset 2.00
State Saved Saved in instrument state
Min 0.1
Max 20
Backwards
Compatibility
SCPI
:DISPlay:PSTatistic:XSCale
3.6.10 Trace
Lets you control the display and storage of trace data for the available traces.
3.6.10.1 Trace Control
The controls on this tab allow you to select display of the Reference Trace and the
Gaussian Line, and store the Reference Trace.
Store Ref Trace
Copies the currently measured curve as the user-definable reference trace. The
captured data remains until the other mode is chosen. Pressing this key also
refreshes the reference trace.
No query is available.
Remote Command
:CALCulate:PSTatistic:STORe:REFerence
Example
:CALC:PST:STOR:REF
Backwards Compatibility
SCPI
[:SENSe]:PSTatistic:SRTRace
Ref Trace
Toggles the reference trace display On or Off.
Short Range Comms & IoT Mode User's &Programmer's Reference 771
