6 Input/Output

6.1 RF Source

Min 1

Max Step Count

Insert Step Before

Inserts a new step, with default values, before the currently selected step. Inserting

a step automatically increases the Step Count parameter by 1. If a sequence has

already reached the upper limit of 1000 steps, then this operation is rejected, and

error -221, “Setting Conflict; Cannot insert more steps, maximum number of steps

reached” is displayed.

Notes If the list already contains the maximum limit (1000 steps), pressing this control has no effect

Delete Step

Deletes the current step. Deleting a step automatically decreases the Step Count

parameter by 1. If the sequence only has one step left, then this operation is

rejected, and error -221, “Setting conflict; Cannot delete current step, minimum

number of steps reached” is displayed

Notes If the list already contains the minimum limit of 1 step, pressing this control has no effect

Clear List

Clears the list. Clearing the list sets the number of steps to the default value (1) and

sets the parameters for the only step to their default values.

Step Trigger

Lets you select the trigger input for the current step.

Remote Command

EXTernal2 | KEY | BUS | EXTernal4

For details of options, see "More Information" on page 1936

:SOURce:LIST:STEP[1]|2|…|1000:SETup:INPut:TRIGger?

Example

:SOUR:LIST:STEP2:SET:INP:TRIG BUS

:SOUR:LIST:STEP2:SET:INP:TRIG?

Notes SCPI is supported after A.09.40

Dependencies Not available in E7760B

Preset

IMMediate

Range

1935 Short Range Comms & IoT Mode User's &Programmer's Reference
