3 Short-Range Comms & IoT Mode
3.8 SEM Measurement
OFFSet1 is for BTS, 2 for MS. Default is BTS
Note that Offset sub op code 2 is supported only in non-SA modes. In the SA mode, Offset sub op code
1 is used for both BTS and MS
Preset Modes other than LTEAFDD, LTEATDD, 5G NR, MSR, WLAN:
When the max number of offsets is 6:
0.01, 0.01, 0.01, 0.01, 0.01, 0.01|0.01, 0.01, 0.01, 0.01, 0.01, 0.01
When the max number of offsets is 12, the preset value of Offset G ~ L is the same as the Offset F value
LTEAFDD, LTEATDD, 5G NR, MSR Modes:
0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01, 0.01|0.01, 0.01, 0.01, 0.01, 0.01, 0.01,
0.01, 0.01, 0.01, 0.01, 0.01, 0.01
When the max number of offsets is 14 in these modes, the preset value of Offset G ~ N is the same as
the Offset F value
WLAN Mode:
802..11 ax/be: 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075, 0.075,
0.075, 0.075
All other formats: 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3, 0.3
Modes other than WLAN
When the max number of offsets is 6:
OFF, OFF, OFF, OFF, OFF, OFF | OFF, OFF, OFF, OFF, OFF, OFF
When the max number of offsets is 12:
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF | OFF, OFF, OFF,
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
WLAN Mode:
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF | OFF,
OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF, OFF
State Saved Saved in instrument state
Saved in instrument state
Range Auto|Man
Min/Max 0.00001/3000000
Backwards
Compatibility
SCPI
[:SENSe]:SEMask:OFFSet[1]|2:LIST:BWIDth:VIDeo:RATio
[:SENSe]:SEMask:OFFSet[1]|2:LIST:BWIDth:VIDeo:RATio:AUTO
Offset (Sweep)
Accesses a menu that enables you to set up the sweep measurement parameters for
offset pairs.
Offset Freq Define
Same as "Offset Freq Define" on page 1099 under Offset (Bandwidth).
1116 Short Range Comms & IoT Mode User's &Programmer's Reference
