Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
3.7.10 Display
Lets you configure display items for the current Mode, Measurement, View, or
Window.
3.7.10.1 Meas Display
Contains controls for setting up the display for the current Measurement, View or
Window.
Bar Graph On/Off
Turns the Bar Graph On or Off.
Remote Command
:DISPlay:ACPower:WINDow[1]:BGRaph OFF | ON | 0 | 1
:DISPlay:ACPower:WINDow[1]:BGRaph?
Example
:DISP:ACP:WIND:BGR OFF
:DISP:ACP:WIND:BGR?
Dependencies Always set to ON and grayed-out when the method is RBW
Preset
ON
State Saved Saved in instrument state
Range
OFF|ON
Backwards Compatibility
SCPI
:DISPlay:ACPower:VIEW[1]:WINDow[1]:BGRaph
3.7.10.2 Annotation
Contains controls for setting up the annotation for the current Mode or
Measurement.
Graticule
Turns the display graticule On or Off for all windows with graticules in all
measurements in the current Mode. Also turns the graticule Y-Axis annotation on
and off.
Remote
Command
:DISPlay:GRATicule[:STATe] OFF | ON | 0 | 1
:DISPlay:GRATicule[:STATe]?
Example
:DISP:GRAT OFF
836 Short Range Comms & IoT Mode User's &Programmer's Reference
