4 System
4.2 I/O Config
Preset Unaffected by Preset, but set to ON by Restore Defaults >"Misc" on page 1798
If not set up or specified, the Secure Instrument Communications configuration setting: is ON
State Saved No
Range
OFF|ON
4.2.2.3 SICL Server
Turns the SICL Server capability ON or OFF, to limit SCPI access over LAN through
the SICL server. (SICL IEEE 488.2 protocol.)
Parameter Description Setting
Maximum
Connections
The maximum number of connections that can be accessed
simultaneously
5
Instrument
Name
The name (same as the remote SICL address) of your instrument inst0
Instrument
Logical Unit
The unique integer assigned to your instrument when using SICL
LAN
8
Emulated GPIB
Name
The name (same as the remote SICL address) of the device used
when communicating with your instrument
gpib7
Emulated GPIB
Logical Unit
The unique integer assigned to your device when it is being
controlled using SICL LAN
8
Emulated GPIB
Address
The emulated GPIB address assigned to your transmitter tester
when it is a SICL server (the same as your GPIB address)
18
Connection String & Copy Button
In "SCPI LAN" on page 1750, the full connection string is displayed to the right of
the SICL ServerON/OFF control. Pressing Copy, to the right of the string copies the
connection string to the Windows clipboard.
Remote Command
:SYSTem:COMMunicate:LAN:SCPI:SICL:ENABle OFF | ON | 0 | 1
:SYSTem:COMMunicate:LAN:SCPI:SICL:ENABle?
Example
:SYST:COMM:LAN:SCPI:SICL:ENAB OFF
Dependencies Not available in UXM
If the Secure Instrument Communications configuration has disabled this connection, local changes
are not allowed, and an attempt to do so results in error -221,“Disabled by Secure Instrument
Communications configuration”
Preset Unaffected by Preset, but set to ON by Restore Defaults >"Misc" on page 1798
If not set up or specified, the Secure Instrument Communications configuration setting: is ON
State Saved No
Range
OFF|ON
Short Range Comms & IoT Mode User's &Programmer's Reference 1752
