Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.5 Channel Power Measurement
Example
:CHP:AVER:TCON EXP
:CHP:AVER:TCON?
Preset
EXP
State Saved Yes
Range
EXPonential|REPeat
Integ BW
Specifies the range of integration used in calculating the power in the channel. The
integration bandwidth (IBW) is displayed on the trace as two markers connected by
an arrow.
Remote Command
[:SENSe]:CHPower:BANDwidth:INTegration <bandwidth>
[:SENSe]:CHPower:BANDwidth:INTegration?
Example
:CHP:BAND:INT 10MHz
:CHP:BAND:INT?
Dependencies For LTE-Advanced FDD/TDD, 5G NR and MSR Modes, this control is not shown
Couplings The minimum value of the span is coupled with Integ BW
When you change Integ BW, the span changes accordingly by keeping the same ratio of Span/Integ
BW
Preset
Mode Radio Std Integ BW
SA 2 MHz
WCDMA 5 MHz
LTEAFDD, LTEATDD 5 MHz
WLAN 802.11a/g(OFDM/DSSS-OFDM) 20 MHz
802.11b 25 MHz
802.11n/ac/ax/be (20MHz) 20 MHz
802.11n/ac/ax/be (40MHz) 40 MHz
802.11n/ac/ax/be (80MHz) 80 MHz
802.11ax/be (80 MHz + 80 MHz) 80 MHz
802.11ac/ax/be (160 MHz) 160 MHz
802.11be (160 MHz + 160MHz) 160 MHz
802.11be (320MHz) 320 MHz
State Saved Saved in instrument state
Min/Max 100 Hz / Hardware Maximum Span
Backwards
Compatibility SCPI
[:SENSe]:CHPower:BWIDth:INTegration
Short Range Comms & IoT Mode User's &Programmer's Reference 627
