3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
M9415E/16E
Option Limitation:
Option Maximum IF BW
B4X 400 MHz
B8X 800 MHz
B12 1200 MHz
Center Frequency Limitation:
Center Frequency Maximum IF BW
1 MHz ~ 10 MHz (Option LFE) 500 kHz
10 MHz ~ 20 MHz (Option LFE) 5 MHz
20 MHz ~ 60 MHz (Option LFE) 10 MHz
60 MHz ~ 80 MHz (Option LFE) 20 MHz
80 MHz ~ 380 MHz (Option LFE) 40 MHz
330 MHz ~ 380 MHz (without Option LFE) (CF – 330 MHz) * 2
380 MHz ~ 550 MHz 100 MHz
550 MHz ~ 1310 MHz 200 MHz
1310 MHz ~ 2000 MHz 600 MHz
2000 MHz ~ 25.9 GHz 1200 MHz
25.9 GHz ~ 26.5 GHz Min(Max BW by option, 2*(26.5 GHz-Center Freq))
Auto Couple
Immediately puts all Auto/Man functions into Auto. Auto Couple is confined to the
current measurement only. It does not affect other measurements in the Mode.
In the Auto state, Auto/Man functions are said to be “coupled”, meaning their values
change as you make changes to other values in the measurement. This helps ensure
accurate measurements and optimum dynamic range. Auto Couple is an immediate
action function, and when it is executed, all the Auto/Man controls for the current
measurement are set to Auto, and all measurement settings coupled to the
Auto/Man parameters are automatically set to their optimal values.
For further details of measurement-specific settings (if any), see "Measurement-
Specific Details" on page 1601 below.
Remote
Command
:COUPle ALL
1600 Short Range Comms & IoT Mode User's &Programmer's Reference
