Keysight x-series Instruction Manual

7 Save/Recall/Print
7.3 Save
LTEAFDD and LTEATDD Modulation Analysis measurements, LTEAFDD and LTEATDD
CEVM measurements
Example
:MMEM:STORe:RECording "C:\TEMP\MyIQData.csv"
7.3.56 Channel
Select data channels to save. This is only supported by 5GNR Mode’s EVM, VMA
Digital Demod, VMA Custom OFDM measurements, and by WLAN Mode’s MIMO
EVM measurement.
The <meas> param in the command must be replaced with the node of the active
measurement:
Parameter Mode Measurement
EVM
5GNR EVM
EVMM
WLAN MIMO EVM
DDEM
VMA Digital Demod
OFDM
VMA Custom OFDM
Remote
Command
:MMEMory:STORe:<meas>:RECording:CHANnel ALL | CH1 | CH2 | CH3 | CH4 | CH5 |
CH6 | CH7 | CH8
:MMEMory:STORe:<meas>:RECording:CHANnel?
Example
:MMEM:STOR:EVM:REC:CHAN CH1
:MMEM:STOR:EVM:REC:CHAN?
Preset
ALL
State Saved No
Range
ALL|CH1|CH2|CH3|CH4|CH5|CH6|CH7|CH8
7.3.57 Remote Only Commands
The following commands execute file system operations such as move, copy, and
transfer data from a file.
7.3.58 Mass Storage Catalog (Remote Command Only)
Remote
Command
:MMEMory:CATalog? [<directory_name>]
The string <directory_name> must be a valid logical path. If no string then it uses the current
directory
Example
:MMEM:CAT? "C:\"
Short Range Comms & IoT Mode User's &Programmer's Reference 2305

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
