9 Programming the Instrument
9.4 Status Register System & STATus Subsystem
Bit Condition Operation
10 RCal Multiple Calibrations
Applied, Part of Trace
More than one calibration is being applied to part of the
trace for current measurement
11 RCal Calibrations Missing,
Part of Trace
The calibration being applied is not being applied to all of
the trace for the current measurement
12 RCal Multiple Groups
Applied
More than one calibrated rows are being applied to the
current measurement
14 Misc/System Alignment
Failure
Miscellaneous/System alignments have failed
Filter Registers
–
"Questionable Calibration Extended Failure Condition" on page 2492
–
"Questionable Calibration Extended Failure Enable" on page 2492
–
"Questionable Calibration Extended Failure Event Query" on page 2493
–
"Questionable Calibration Extended Failure Negative Transition" on page 2493
–
"Questionable Calibration Extended Failure Positive Transition" on page 2494
Questionable Calibration Extended Failure Condition
Returns the decimal value of the sum of the bits in the Questionable Calibration
Extended Failure Condition register.
NOTE
The data in this register is continuously updated and reflects the current
conditions.
Remote
Command
:STATus:QUEStionable:CALibration:EXTended:FAILure:CONDition?
Example
:STAT:QUES:CAL:EXT:FAIL:COND?
Preset 0
Status Bits/OPC
dependencies
Sequential command
Questionable Calibration Extended Failure Enable
Determines which bits in the "Questionable Calibration Extended Failure Condition"
on page 2492 Register will set bits in the "Questionable Calibration Extended Failure
Event Query" on page 2493 register, which also sets bit 9 of the "Questionable
Calibration Register" on page 2484.
Short Range Comms & IoT Mode User's &Programmer's Reference 2492
