6 Input/Output

6.9 Calibration

6.9.1.9 Select Calibrator

Selects the calibrator for the currently selected Cal Group to use for executing the

calibration when multiple modules are connected.

Remote Command

:SYSTem:CALibration:MODule:SELect NONE | RCM1 | RCM2 | RCM3 | RCM4 | RCM5 |

RCM6 | RCM7 | RCM8 | RCM9 | RCM10

:SYSTem:CALibration:MODule:SELect?

Example

:SYST:CAL:MODule:SELect RCM1

Notes Details of the RCal module are displayed beneath the control. If there are no modules connected, the

text states “No Modules Connected”

For SCPI, if the parameter sent is for a module that is not currently connected to the instrument, the

message “Selected RCal module not connected” is generated

Dependencies The SCPI command is applied to the currently selected Cal Group

State Saved Saved in instrument state

Range All connected RCal modules

6.9.1.10 Identify RCal Module

Control to connect to the RCal module of the currently selected Cal Group and blink

its identity light

6.9.1.11 RCal Module Serial Number (Remote Query Only)

Returns the serial number of the specified module

Remote

Command

:SYSTem:CALibration:MODule[1]|2|...|10:SNUMber?

Example

:SYST:CAL:MOD:SNUM?

Notes If there is no module associated with the specified module number, returns an empty string

6.9.1.12 RCal Reference

Determines the reference type used by the RCal module of the currently selected

Cal Group

Remote Command

:SYSTem:CALibration:REFerence INTernal | EXTernal

:SYSTem:CALibration:REFerence?

Example

:SYST:CAL:REF EXT

Dependencies The SCPI command is applied to the currently selected Cal Group

Short Range Comms & IoT Mode User's &Programmer's Reference 2184
