3 Short-Range Comms & IoT Mode
3.10 Spurious Emissions Measurement
Preset Automatically calculated
State Saved Saved in instrument state
Min 0.10 dB
Max 20 dB
Annotation <value> dB/ left upper of graph
Backwards
Compatibility
SCPI
:DISPlay:SPURious:VIEW[1]:WINDow[1]:TRACe:Y[:SCALe]:PDIVision
Scale Range
Sets the Y-Axis scale range.
Remote Command Replace <meas> with the identifier for the current measurement
:DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe <rel_ampl>
:DISPlay:<meas>:WINDow[1]:TRACe:Y[:SCALe]:RANGe?
Example
:DISP:CHP:WIND:TRAC:Y:RANG 100
:DISP:CHP:WIND:TRAC:Y:RANG?
Couplings Coupled to Scale/Div as follows
Scale Range = Scale/Div * 10 (number of divisions)
When you change this value, Auto Scaling automatically changes to OFF
Preset 100 dB
State Saved Saved in instrument state
Min 1
Max 200
Ref Position
Positions the reference level at the top, center, or bottom of the Y Scale display.
Changing the reference position does not change the reference level value.
Preset
TOP
State Saved Saved in instrument state
Range Top | Center | Bottom
Annotation The greater than (>) and less than (<) symbols are displayed on both sides of the graph to indicate the
Reference Position
Auto Scaling
Toggles Auto Scaling On or Off.
Short Range Comms & IoT Mode User's &Programmer's Reference 1363
