3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Auto, this cell is grayed-out and disabled. Since Res BW Mode for the offset is preset to Auto on
changing "Meas Method" on page 863 to RBW, FAST or Fast Power, this cell is also grayed-out and
disabled. If the cell is pressed, an advisory message is generated. If the equivalent remote command is
sent, a "Setting conflict" warning is generated
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is DB3
DB3, DB3, DB3, DB3, DB3, DB3
State Saved Saved in instrument state
Range –3 dB (Normal) | –6 dB
Power Ref Type
Lets you set reference types of inner offsets.
CUMulative
Cumulated power of the upper and lower sub-block carriers is the reference level. This selection is
effective only when one of the following "Power Ref" on page 948 values is selected:
Left & Right Carriers
LRCarriers
Max Power Carrier in Sub-block
MPCSubblock
Min Power Carrier in Sub-block
MINSubbloc
Left & Right Sub-blocks
LRSubblocks
Manual
MANual
When one of the other Power Ref values is selected, carrier powers are not cumulated, and the
reference level is equivalent to Normal
NORMal
Power of specified carrier or the manual reference level is the reference level
Remote
Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:PREFerence CUMulative | NORMal, …
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:PREFerence?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:INN:LIST:PREF CUM,CUM,NORM,NORM,NORM,NORM
:ACP:OFFS:INN:LIST:PREF?
Preset When "Max Num of Offsets" on page 902 is 12, the preset value of Offset G ~ L is NORMal
NORMal, NORMal, NORMal, NORMal, NORMal, NORMal
State Saved Saved in instrument state
Range
CUMulative|NORMal
Auto Function
Remote Command
[:SENSe]:ACPower:OFFSet[1]|2:INNer:LIST:PREFerence:AUTO OFF | ON | 0 | 1, …
[:SENSe]:ACPower:OFFSet[1] | 2:INNer:LIST:PREFerence:AUTO?
Subopcode: 1 = BTS/Downlink (Default), 2 = MS/Uplink
Example
:ACP:OFFS:INN:LIST:PREF:AUTO OFF,OFF,OFF,OFF,OFF,OFF
Short Range Comms & IoT Mode User's &Programmer's Reference 939
