Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.9 Occupied BW Measurement
The menus and command options are as follows:
NFE State Modes with
Adaptive NFE
Modes without
Adaptive NFE
SCPI
Off Off Off See "NFE On/Off Command" on
page 1309
On Full On
Adaptive Adaptive n/a See "Adaptive NFE Command" on
page 1310
As shown in the table above, the On state (in Modes that do not support Adaptive
NFE) matches the Full state in Modes that do support Adaptive NFE.
To maintain SCPI backwards compatibility, the existing command to turn NFE on or
off is retained, and a new command is added to set the state to turn AdaptiveON or
OFF:
–
[:SENSe]:CORRection:NOISe:FLOor ON|OFF|1|0 is retained, with the
default changed to ON for Modes that support Adaptive NFE
–
[:SENSe]:CORRection:NOISe:FLOor:ADAPtive ON|OFF|1|0 is added (for
certain Modes), default = ON
When NFE is On or Full, the expected noise power of the instrument (derived from a
factory calibration) is subtracted from the trace data. This will usually reduce the
apparent noise level by about 10dB in low band, and 8dB in high band (>~3.6GHz).
NFE works with any RBW, VBW, detector, any setting of Average Type, any amount
of trace averaging, and any signal type. It is ineffective when the trace is not
smoothed (smoothing processes include narrow VBWs, trace averaging, and long
sweep times with the detector set to Average or Peak). It works best with extreme
amounts of smoothing, and with the average detector, with the Average Type set to
Power.
In those cases where the cancellation is ineffective, it nonetheless has no
undesirable side-effects. There is no significant speed impact to having Noise Floor
Extension on.
The best accuracy is achieved when substantial smoothing occurs in each point
before trace averaging. Thus, when using the Average detector, results are better
with long sweep times and fewer trace averages. When using the Sample detector,
the VBW filter should be set narrow with less trace averaging, instead of a wide VBW
filter with more trace averaging.
NOTE
Noise Floor Extension has no effect unless the RF Input is selected, so when
External Mixing is selected, it does nothing.
For more details, see "Optimal Detector & Averaging Selections" on page 1310 and
"Recalibration of Noise Floor" on page 1311.
1308 Short Range Comms & IoT Mode User's &Programmer's Reference
