Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.11 IQ Waveform Measurement
Remote Command
[:SENSe]:WAVeform:SAVoid[:STATe] ON | OFF | 0 | 1
[:SENSe]:WAVeform:SAVoid[:STATe]?
Example
:WAV:SAVoid ON
:WAV:SAVoid?
Dependencies Only appears in VXT models M9410A/11A/15A/16A and M9410E/11E/15E/16E
Preset
OFF
State Saved Saved in instrument state
Range
ON|OFF
More Information
The Maximum Digital IF BW depends on the installed options, and selected Center
Frequency.
VXT models M9410A/11A
Option limitation:
Option Max Digital IF BW
B40 40 MHz
B3X 300 MHz
B6X 600 MHz
B12 1200 MHz
Center frequency limitation:
Center Frequency Max Digital IF BW
330 MHz ~ 380 MHz (CF – 330 MHz) * 2
380 MHz ~ 550 MHz 100 MHz
550 MHz ~ 1310 MHz 200 MHz
1310 MHz ~ 2000 MHz (without Option EP6) 600 MHz
2000 MHz ~ 5480 MHz (without Option EP6) 1200 MHz
5480 MHz ~ 6080 MHz (without Option EP6) (6080 MHz – CF) * 2
1310 MHz ~ 1900 MHz (Option EP6) 600 MHz
1900 MHz ~ 6000 MHz (Option EP6) 1200 MHz
6000 MHz ~ 6600 MHz (Option EP6) (6600 MHz – CF) * 2
VXT models M9415A/16A
Option limitation:
1598 Short Range Comms & IoT Mode User's &Programmer's Reference
