4 System

4.6 Alignments

NOTE

Connect the RF In of the primary module to the OUT port (COMMON, PORT 1)

of the combiner.

NOTE

Before performing Path Delay Calibration of Sources, please confirm that:

–

NOTE

Each of the RF Out ports is connected to the RF In port of the Primary

channel, using an RF combiner.

–

NOTE

The cables between the combiner and the Source output ports are of the

same length.

NOTE

A pop-up window appears (as shown below); press OK to continue calibration.

NOTE

If the is in MIMO sync, and you send a SCPI command to run Calibration, the

calibration process is not executed and instrument a warning is generated (“-

221,Setting Conflict; Calibrations are not available while MIMO Sync is On”). To

execute Calibration, you must first stop MIMO, manually or via SCPI.

Remote Command

:CALibration:PDELay:SOURce

:CALibration:PDELay:SOURce?

Example

:CAL:PDEL:SOUR

Notes The query initiates an Alignment and returns 0 if successful, or 1 if failed

If the calibration process detected a faulty state, an error will be generated: “Misc/System Alignment

Failure”. Calibration will be aborted. Please see event log for more information:

Cables are not connected

Power control failure

Hardware failure

M9300A 10MHz reference open failure

Dependencies Only appears in VXT models M9410A/11A

Only for modules with matched Digital board hardware version, which means the modules are in same

FPGA version

Short Range Comms & IoT Mode User's &Programmer's Reference 1828
