Keysight x-series Instruction Manual

6 Input/Output
6.1 RF Source
VXT model M9420A
RF Output
Port
Frequency
Range
Min Output
Power
Max Output Power
without Option “1EA”
Max Output Power
with Option “1EA”
RF Output 60 MHz ≤ f ≤ 6
GHz
–150 dBm 10 dBm 25 dBm
RFHD 60 MHz ≤ f ≤ 6
GHz
–150 dBm 10 dBm 15 dBm
RFFD 60 MHz ≤ f ≤ 6
GHz
–150 dBm 0 dBm 0 dBm
Note 1: This is the UI power range, which is larger than the actual specification.
Note 2: Max output power with Option 1EA can be set to 25 dBm, but Meas Uncal
(measurement uncalibrated) warning is given in the Status Bar in the lower right
corner of the screen when output power set higher than 20 dBm.
VXT models M9410A/11A
Ports Option LFE Frequency
Range
Min Output
Power
Max Output
Power without
option “1EA”
Max Output
Power with
“1EA”
RF Output With Option
LFE
1 MHz ≤ f ≤ 60
MHz
–150 dBm 5 dBm 5 dBm
60 MHz ≤ f ≤
380MHz
–150 dBm 5 dBm 25 dBm
Without
Option LFE
380 MHz ≤ f ≤
6 GHz
–150 dBm 5 dBm 25 dBm
RFHD 1 MHz ≤ f ≤ 6
GHz
–150 dBm 5 dBm 5 dBm
Note 1: Min Output Power is the UI power range, which is smaller than the actual
specification.
Note 2: Max output power with Option 1EA can be set to 25 dBm for RF Output Port,
but Meas Uncal (measurement uncalibrated) warning is given in the Status Bar in
the lower right corner of the screen when the output power is set higher than 20
dBm.
Note 3: Option LFE provides Low Frequency Extension, which covers frequency from
1 MHz to 380 MHz.
Short Range Comms & IoT Mode User's &Programmer's Reference 1926

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
