6 Input/Output
6.1 RF Source
The relation between EARFCN and the carrier frequency in MHz for the uplink is
given by the following equation where F
UL_low
and N
Offs-UL
are given in table 5.4.4-
1 and N
UL
is the uplink EARFCN.
F
UL
= F
UL_low
+ 0.1(N
UL
– N
Offs-UL
)
Band Downlink Uplink
F
DL_low
(MHz) N
Offs-DL
Range of N
DL
F
UL_low
(MHz) N
Offs-UL
Range of N
UL
1 2110 0 0 – 599 1920 18000 18000 – 18599
2 1930 600 600 – 1199 1850 18600 18600 – 19199
3 1805 1200 1200 – 1949 1710 19200 19200 – 19949
4 2110 1950 1950 – 2399 1710 19950 19950 – 20399
5 869 2400 2400 – 2649 824 20400 20400 – 20649
6 875 2650 2650 – 2749 830 20650 20650 – 20749
7 2620 2750 2750 – 3449 2500 20750 20750 – 20449
8 925 3450 3450 – 3799 880 21450 21450 – 21799
9 1844.9 3800 3800 – 4149 1749.9 21800 21800 – 22149
10 2110 4150 4150 – 4749 1710 22150 22150 – 22749
11 1475.9 4750 4750 – 4949 1427.9 22750 22750 – 22949
12 729 5010 5010 – 5179 699 23010 23010 – 23179
13 746 5180 5180 – 5279 777 23180 23180 – 23279
14 758 5280 5280 – 5379 788 23280 23280 – 23379
…
17 734 5730 5730 – 5849 704 23730 23730 – 23849
18 860 5850 5850 – 5999 815 23850 23850 – 23999
19 875 6000 6000 – 6149 830 24000 24000 – 24149
20 791 6150 6150 – 6449 832 24150 24150 – 24449
21 1495.9 6450 6450 – 6599 1447.9 24450 24450 – 24599
…
24 1525 7700 7700 - 8039 1626.5 25700 25700 – 26039
25 1930 8040 8040 - 8689 1850 26040 26040 - 26689
26 859 8690 8690 - 9039 814 26690 26690 - 27039
...
Note: The channel numbers that designate carrier frequencies so close to the
operating band edges that the carrier extends beyond the operating band edge
shall not be used. This implies that the first 7, 15, 25, 50, 75 and 100 channel
numbers at the lower operating band edge and the last 6, 14, 24, 49, 74 and 99
channel numbers at the upper operating band edge shall not be used for channel
bandwidths of 1.4, 3, 5, 10, 15 and 20 MHz respectively.
