6 Input/Output
6.2 Input
EIA Keysight Freq Range
WR-28 A 26.5 - 40 GHz
WR-22 Q 33 - 50 GHz
WR-19 U 40 - 60 GHz
WR-15 V 50 - 75 GHz
WR-12 E 60 - 90 GHz
WR-10 W 75 - 110 GHz
WR-8 F 90 - 140 GHz
WR-6 D 110 - 170 GHz
WR-5 G 140 - 220 GHz
WR-3 J 220 - 325 GHz
Preset When Restore Input/Output Defaults is performed, an “A” mixer preset is also issued (11970A band),
unless a Keysight USB Mixer is plugged into the instrument’s USB port, in which case the Mixer
Selection remains unchanged
When using Keysight USB Mixers, if Restore All Defaults (:SYSTem:DEFault) has been performed,
either remove and reinsert the USB cable or press the Refresh USB Mixer Connection control
VDI CCD (N9029)
These presets select a setup that uses a single harmonic and no LO doubling.
This setup is used with an external mixer in the series VDI CCD (N9029ACST). The
currently supported example is the D-band mixer VDI WR6.5CCD-M4.
Mixer Readout on setup dialog
and menu panel
Harm # RF start RF stop RF center
WR6.5 M4
(D-band)
VDI WR6.5CCD-M4 -4 110 170 140
This mixer setup is enabled only for model N9042B with the EXW option You must
connect cables from this external mixer to the High LO Out and High IF In ports (not
the Ext Mixer port) of the N9042B, as illustrated below:
2059 Short Range Comms & IoT Mode User's &Programmer's Reference
