Keysight x-series Instruction Manual

6 Input/Output
6.11 Advanced
“CAUTION! Over temperature has been detected at the T/R Port. The input has been
disconnected. Remove the signal, allow to cool & press OK”
Until you press OK, the input remains disconnected, and no measurement can be
made.
Remote Command
[:SENSe]:FEED:RF:PORT:TR:HPOWer:ATTenuator[:STATe] ON | OFF
[:SENSe]:FEED:RF:PORT:TR:HPOWer:ATTenuator[:STATe]?
Example
:FEED:RF:PORT:TR:HPOW:ATT ON
:FEED:RF:PORT:TR:HPOW:ATT?
Dependencies Only appears in modular analyzers, and only when the M9470A module is installed, such as in
M8920A. Option HDX is required to enable the T/R port
Preset
ON
State Saved Saved in instrument state
2219 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
