Keysight x-series Instruction Manual

8 Trigger
8.6 Auto/Holdoff
having been below the threshold for at least the holdoff time. For negative slope, the
trigger event is generated if the signal characteristic crosses the threshold (with
negative slope) and then remains below the threshold for at least the holdoff time. In
either case, the trigger event is associated with the time the level was crossed
Remote Command
:TRIGger[:SEQuence]:HOLDoff:TYPE NORMal | ABOVe | BELow
:TRIGger[:SEQuence]:HOLDoff:TYPE?
Example
:TRIG:HOLD:TYPE NORM
Preset
Modes Setting
GSM/EDGE
Bluetooth
BELow
All others
NORMal
State Saved Saved in instrument state
2383 Short Range Comms & IoT Mode User's &Programmer's Reference

Keysight x-series Specifications

General

Analysis Bandwidth	Up to 1 GHz (depending on model)
Real-Time Bandwidth	Up to 1 GHz (depending on model)
Form Factor	Benchtop
Connectivity	LAN, USB, GPIB
Resolution Bandwidth	1 Hz to 10 MHz (depending on model)
