3 Short-Range Comms & IoT Mode
3.3 LoRa (CSS) Demodulation Measurement
Window Average Type
RF Spectrum Pwr Average
Demod Waveform Arithmetic Average
Frequency Drift vs. Symbols Arithmetic Average
AF Spectrum Log Average
Remote
Command
[:SENSe]:LORA:AVERage:COUNt <integer>
[:SENSe]:LORA:AVERage:COUNt?
[:SENSe]:LORA:AVERage[:STATe] ON | OFF | 1 | 0
[:SENSe]:LORA:AVERage[:STATe]?
Example
:LORA:AVER:COUN 10
Preset 10
OFF
State Saved Saved in instrument state
Min 1
Max 9999
Annotation The average count is displayed on the measurement bar on the front panel display. The annotation
displays in the format of n/N where n is the current average and N is the average count
Average/Hold On/Off Functionality
Average, Minhold, and Maxhold are coupled.
When average/max hold is on:
The RF Spectrum and AF Spectrum traces are averaged.
The demod waveform window and the frequency drift window will display a current
trace, an averaged trace, a max hold trace, and a min hold trace.
The metrics window will display an “average” column and a “max hold” column.
Metrics will display to four significant digits.
The meas bar will display the average/hold number (along with how many of those
sweeps have been captured).
Demod min trace, demod max trace, and demod avg trace are maintained.
The max hold column shows the maximum value the un-averaged metric has
attained since the last Restart.
When average/max hold is off:
Short Range Comms & IoT Mode User's &Programmer's Reference 399
