Keysight x-series Instruction Manual

3 Short-Range Comms & IoT Mode
3.6 Power Stat CCDF Measurement
Example
:FREQ:CENT:AUTO OFF
:FREQ:CENT:AUTO?
Dependencies Only available for the Monitor Spectrum, Power Stat CCDF and IQ waveform measurements in MSR,
LTE-Advanced FDD/TDD and 5G NR Modes
Couplings When Center Frequency changes, state automatically changes to Manual (OFF)
Center Frequency, Center Frequency Offset and Carrier Reference Frequency are coupled. When
Carrier Reference Frequency changes:
Center
Frequency
Relationship
Auto Center Frequency = Carrier Reference Frequency + Center Frequency Offset
(fixed)
Man Center Frequency (fixed) = Carrier Reference Frequency + Center Frequency
Offset
Preset
ON
State Saved Saved in instrument state
Range
Auto|Man
Center Frequency Presets
The following table provides the Center Frequency Presets for the Spectrum
Analyzer mode, and the Max Freq, for the various frequency options:
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
503 (all but CXA) 1.805 GHz 3.6 GHz 3.7 GHz
503 (CXA) 1.505 GHz 3.0 GHz 3.08 GHz
507 (all but CXA) 3.505 GHz 7.0GHz 7.1 GHz
507 (CXA) 3.755 GHz 7.5GHz 7.58 GHz
508 (all but MXE) 1.805 GHz 3.6GHz 8.5 GHz
508 (MXE) 4.205 GHz 8.4GHz 8.5 GHz
513 6.805 GHz 13.6GHz 13.8 GHz
526 (except CXA and
MXE)
13.255 GHz 26.5 GHz 27.0 GHz*
526 (CXA) 13.255 GHz 26.5GHz 26.55 GHz
526 (MXE) 1.805 GHz 3.6GHz 27.0 GHz
532 16.005 GHz 32.0GHz 32.5 GHz
540 20.005 GHz 40.0GHz 40.5GHz
543 21.505 GHz 43.0 GHz 43.0 GHz
544 22.005 GHz 44.0 GHz 45.0 GHz
Short Range Comms & IoT Mode User's &Programmer's Reference 745
