3 Short-Range Comms & IoT Mode
3.7 ACP Measurement
Measurement Type = Power Spectral Density Reference
Conditions Results
Mode: LTEAFDD,
LTEATDD, 5GNR, MSR
"Power Ref" on page
948:
LRCarriers
LRSubblocks
MPCSubblock
MINSubbloc
For the trace specified by "Measure Trace" on page 1508, returns comma-separated scalar
results in the following order:
# Item Unit, if any
1 0.0
2 Total carrier power dBm/Hz or dBm/MHz*
3 Left reference power dBm/Hz or dBm/MHz*
4 Right reference power dBm/Hz or dBm/MHz*
5 Lower offset A - relative power dB
6 Lower offset A - absolute power dBm/Hz or dBm/MHz*
7 Upper offset A - relative power dB
8 Upper offset A - absolute power dBm/Hz or dBm/MHz*
9 Lower offset B - relative power dB
10 Lower offset B - absolute power dBm/Hz or dBm/MHz*
11 Upper offset B - relative power dB
12 Upper offset B - absolute power dBm/Hz or dBm/MHz*
When "Max Num of Offsets" on page 902 is 6, returns 28 results (Offset A-F: 28 = 4 + 4*6) and
when set to 12, returns 52 results (Offset A-L: 52 = 4 + 4 * 12)
*The unit is determined by "PSD Unit" on page 955: DBMHZ or DBMMHZ
If any result is not available, -999.0 is returned
This trace includes only outer offset results and their reference value(s)
All other Modes and
Power Ref settings
For the trace specified by "Measure Trace" on page 1508, returns comma-separated scalar
results in the following order:
# Item Unit, if any
1 0.0
2 Total carrier power dBm/Hz or dBm/MHz*
3 0.0
4 Reference power dBm/Hz or dBm/MHz*
5 Lower offset A - relative power dB
6 Lower offset A - absolute power dBm/Hz or dBm/MHz*
7 Upper offset A - relative power dB
8 Upper offset A - absolute power dBm/Hz or dBm/MHz*
9 Lower offset B - relative power dB
10 Lower offset B - absolute power dBm/Hz or dBm/MHz*
778 Short Range Comms & IoT Mode User's &Programmer's Reference
