R01UH0823EJ0100 Rev.1.00 Page 1063 of 1823

Jul 31, 2019

RX23W Group 33. Serial Communications Interface (SCIg, SCIh)

Figure 33.48 shows the timing of operations in the generation of start, restart, and stop conditions.

Figure 33.48 Timing of Operations in the Generation of Start, Restart, and Stop Conditions

SSDAn

SSCLn

SIMR3.IICSTAREQ

SIMR3.IICRSTAREQ

SIMR3.IICSTPREQ

Start-condition generated

interrupt request

Restart-condition generated

interrupt request

Stop-condition generated

interrupt request

SIMR3.IICSDAS[1:0]

SIMR3.IICSCLS[1:0]

11b

01b

00b

01b

00b

01b 11b
