R01UH0823EJ0100 Rev.1.00 Page 1191 of 1823

Jul 31, 2019

RX23W Group 36. CAN Module (RSCAN)

Transmit history function Stores the history information of transmitted messages.

Bus off recovery mode

selection

Selects a method of returning from bus off state.

 ISO 11898-1 compliant

 Automatic transition to channel halt mode at bus-off entry

 Automatic transition to channel halt mode at bus-off end

 Transition to channel halt mode by a program

 Transition to the error-active state by a program (forcible return from the bus off state)

Error status monitoring

 Monitors CAN protocol errors (stuff error, form error, ACK error, CRC error, bit error, ACK delimiter error,

and bus dominant lock).

 Detects error status transitions (error warning, error passive, bus off entry, and bus off recovery)

 Reads the error counter.

 Monitors DLC errors.

Interrupt source 5 sources

 Global (2 sources)

Global receive FIFO interrupt

Global error interrupt

 Channel (3 sources/channel)

Channel transmit interrupt

– Transmit complete interrupt

– Transmit abort interrupt

– Transmit/receive FIFO transmit complete interrupt

– Transmit history interrupt

Transmit/receive FIFO receive interrupt

Channel error interrupt

CAN clock source Peripheral module clock (PCLK), CANMCLK

Test function Test function for user evaluation

 Listen-only mode

 Self-test mode 0 (external loopback)

 Self-test mode 1 (internal loopback)

 RAM test (read/write test)

Low power consumption Module stop state can be set.

Table 36.1 CAN Module Specifications (2/2)

Item Specification
