RX23W Group 5. I/O Registers
000A 8446h RSCAN Receive Buffer Register 10BH RMPTR10 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8448h RSCAN Receive Rule Entry Register 14AL GAFLIDL14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8448h RSCAN Receive Buffer Register 10CL RMDF010 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Ah RSCAN Receive Rule Entry Register 14AH GAFLIDH14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Ah RSCAN Receive Buffer Register 10CH RMDF110 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Ch RSCAN Receive Rule Entry Register 14BL GAFLML14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Ch RSCAN Receive Buffer Register 10DL RMDF210 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Eh RSCAN Receive Rule Entry Register 14BH GAFLMH14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 844Eh RSCAN Receive Buffer Register 10DH RMDF310 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8450h RSCAN Receive Rule Entry Register 14CL GAFLPL14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8450h RSCAN Receive Buffer Register 11AL RMIDL11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8452h RSCAN Receive Rule Entry Register 14CH GAFLPH14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8452h RSCAN Receive Buffer Register 11AH RMIDH11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8454h RSCAN Receive Rule Entry Register 15AL GAFLIDL15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8454h RSCAN Receive Buffer Register 11BL RMTS11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8456h RSCAN Receive Rule Entry Register 15AH GAFLIDH15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8456h RSCAN Receive Buffer Register 11BH RMPTR11 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8458h RSCAN Receive Rule Entry Register 15BL GAFLML15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8458h RSCAN Receive Buffer Register 11CL RMDF011 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Ah RSCAN Receive Rule Entry Register 15BH GAFLMH15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Ah RSCAN Receive Buffer Register 11CH RMDF111 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Ch RSCAN Receive Rule Entry Register 15CL GAFLPL15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Ch RSCAN Receive Buffer Register 11DL RMDF211 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Eh RSCAN Receive Rule Entry Register 15CH GAFLPH15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 845Eh RSCAN Receive Buffer Register 11DH RMDF311 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8460h RSCAN Receive Buffer Register 12AL RMIDL12 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8462h RSCAN Receive Buffer Register 12AH RMIDH12 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8464h RSCAN Receive Buffer Register 12BL RMTS12 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8466h RSCAN Receive Buffer Register 12BH RMPTR12 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8468h RSCAN Receive Buffer Register 12CL RMDF012 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 846Ah RSCAN Receive Buffer Register 12CH RMDF112 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 846Ch RSCAN Receive Buffer Register 12DL RMDF212 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 846Eh RSCAN Receive Buffer Register 12DH RMDF312 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8470h RSCAN Receive Buffer Register 13AL RMIDL13 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8472h RSCAN Receive Buffer Register 13AH RMIDH13 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8474h RSCAN Receive Buffer Register 13BL RMTS13 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8476h RSCAN Receive Buffer Register 13BH RMPTR13 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8478h RSCAN Receive Buffer Register 13CL RMDF013 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 847Ah RSCAN Receive Buffer Register 13CH RMDF113 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 847Ch RSCAN Receive Buffer Register 13DL RMDF213 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 847Eh RSCAN Receive Buffer Register 13DH RMDF313 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8480h RSCAN Receive Buffer Register 14AL RMIDL14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8482h RSCAN Receive Buffer Register 14AH RMIDH14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8484h RSCAN Receive Buffer Register 14BL RMTS14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8486h RSCAN Receive Buffer Register 14BH RMPTR14 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8488h RSCAN Receive Buffer Register 14CL RMDF014 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 848Ah RSCAN Receive Buffer Register 14CH RMDF114 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 848Ch RSCAN Receive Buffer Register 14DL RMDF214 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 848Eh RSCAN Receive Buffer Register 14DH RMDF314 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8490h RSCAN Receive Buffer Register 15AL RMIDL15 16 16 2 or 3 PCLKB 2 ICLK section 36.
000A 8492h RSCAN Receive Buffer Register 15AH RMIDH15 16 16 2 or 3 PC
LKB 2 ICLK section 36.
000
A 8494h RSCAN Receive Buffer Register 15BL RMTS15 16 16 2 or 3 PCLKB 2 ICLK section 36.
Table 5.1 List of I/O Registers (Address Order) (26/31)
